Automatic Pneumatic Inline Filling Machine with 8 Nozzles Bottle Liquid Filler

Application:

This is an inline piston filling machine for shampoo, ketchup, shower gel, fruit juice, honey, characterized by accurate measuring ,advanced structure ,stable operating ,low noise.

Kindly Reminder:
Please tell us the following information while you send us inquiry. Base on your message, we will suggest the optimum solution to you for reference. Thank you.
1.Your product
2.Packaging Container
3.Output capacity

Chat Now Send E-mail

Benefits & Features

Technical Parameters

VIDEOS

Application

This is an inline piston filling machine for shampoo, ketchup, shower gel, fruit juice, honey, characterized by accurate measuring ,advanced structure ,stable operating ,low noise.

Automatic Pneumatic Inline Filling Machine with 8 Nozzles Bottle Liquid Filler

FEATURES

1.Volume set can be changed on the touch screen. Filling pistons are controlled by servo system.

2. Individual piston adjustment for fine tuning.

3. Digital control system to enable multiple filling actions on the same bottle for double, triple and more.

4. Fully automatic rise for nozzles, adjustment can be done on touch screen.

5. Nozzles can set to be above bottle mouth or bottom up, synchronizing with liquid level (beneath or above) to eliminate bubbling of foamy liquids.

Automatic 8 Heads Servo Piston Liquid Filling Machine Low Viscosity Bottle Filling Machine

WORKFLOW

Automatic Filling

PARAMETER

Eight Heads Piston Pump Liquid Filling Machine
Model	LFZ-04	LFZ-06	LFZ-08	LFZ-10
Filling Range	50-1000ml (customizable)	50-1000ml (customizable)	50-1000ml (customizable)	50-1000ml (customizable)
Production Speed	<15-25 bottles/min	<20-35 bottles/min	<30-40 bottles/min	<40-50 bottles/min
Measurement Accuracy	±1%	±1%	±1%	±1%
Power	2KW	2.5KW	3.5KW	5KW
Voltage	220V, 50Hz	220V, 50Hz	220V, 50Hz	220V, 50Hz
Air consumption	0.6-8Mpa	0.6-8Mpa	0.6-8Mpa	0.6-8Mpa
Weight	600kg	650kg	800kg	800kg
Dimension	L4000W1320H2090(mm)	L4000W1320H2090(mm)	L4000W1320H2090(mm)	L4000W1320H2090(mm)
